228 Maintenance
ENGINE DATA
COOLING SYSTEM DATA TRANSMISSION DATA
Gasoline CNG
Type: Ford
®
4.6L V8 Ford
®
4.6 L 2V EFI V8
Horsepower (net rating): 248 hp @ 4750 rpm 213 hp @ 4750 rpm
Torque: 294 ft-lb @ 4000 rpm 294 ft-lb @ 4000 rpm
Governor Type: Electronic Electronic
Displacement: 281 ci (4.6 L) 281 ci (4.6 L)
Bore and Stroke: 3.55 x 3.54 in (90.2 x 90.0 mm) 3.55 x 3.54 in (90.2 x 90.0 mm)
Compression Ratio: 9.4:1 9.4:1
Idle Speed (engine rpm): Drive = 580/Park = 600 Drive = 580/Park = 600
Oil Type: SAE 5W-20 Premium Synthetic Blend SAE 5W-20 Premium Synthetic Blend
Oil Pressure Minimum at Idle or
3,250 rpm (hot):
40-75 psi (275-517 kPa) 40-75 psi (275-517 kPa)
Cap Pressure: 16 psi
Thermostat: 195°F (90.5°C)
Radiator: 2 Core
Fan: Electric
Normal Operating Coolant
Temperature:
205°F (96.1°C)
Model: Ford
®
4R75E
Type: 4-speed automatic with Overdrive
Oil Type: Mercon
®
LV
Gear Ratios: 2.84, 1.33, 1.00, 0.70
