54 Instrument Cluster
GAUGES
Engine Coolant Temperature Gauge
Indicates engine coolant temperature. At nor-
mal operating temperature, the needle will be in
the normal range (between “H” and “C”). If the
needle enters the red section, the engine is overheating. Stop the
vehicle as soon as safely possible, switch off the engine and let
the engine cool. You should then have your vehicle checked by
your authorized service center as soon as possible.
Never remove the coolant reservoir cap while the engine is
running or hot.
REASON: Steam or hot coolant escaping can cause
injury.
Speedometer
Indicates the current vehicle speed in miles
per hour and kilometers per hour.
Odometer
Registers the total miles of the vehi-
cle.
Trip Odometer
Registers the miles of individual
journeys. Press the SELECT/
RESET stem once to switch from
the odometer to the trip odometer. Press the stem again to
select Trip A and Trip B features. To reset the trip, press and
hold the stem again until the trip is reading 0.0 miles.
Tachometer
Indicates the engine speed in revolutions per
minute. Avoid operating the engine at high
RPM for extended periods of time. The red
line indicates the maximum RPM tolerable.
