52 Instrument Cluster
Vehicle System Malfunction Indicator
Displays when the engine has defaulted to a “limp-
home” operation, which may result in reduced power
and/or limited gear ranges. This could also display
when there is a malfunction in the Automatic Leveling Control
(ALC) system. Report the fault to a service center at the earli-
est opportunity.
WARNING CHIMES
Key-in-Ignition Warning Chime
Sounds when the key is left in the ignition in the OFF or
ACCESSORY position and the driver’s door is open.
Headlamps On Warning Chime
Sounds when the headlamps or parking lamps are on, the igni-
tion is off (the key is not in the ignition) and the driver’s door
is opened.
Parking Brake On Warning Chime
Sounds when the parking brake is set, the engine is running
and the vehicle is driven more than 3 mph (5 km/h).
Ramp Override Warning Chime
Sounds three times when the Power Ramp Deploy switch on
the right rear door is pressed while the “Ramp OFF” Switch in
the center switch bank is active.
BTSI (Brake Transmission Shift Interlock)
Warning Chime
Sounds five times when the brake pedal is depressed and the
operator cannot shift out of park because the right rear door is
open (signifying that the ramp may not be properly stowed).
