Seating and Safety Restraints 85
Before securing a wheelchair, make sure that all the parts of
the restraint system are in good working order and that the
tracks are free from dirt and debris.
Although either securement positions can be used, the rear
position is recommended because it exceeds the ADA wheel-
chair space guidelines of 30 x 40 inches (76 x 102 cm).
The rear wheelchair securement position will be shown for
illustration purposes.
To secure a wheelchair in your vehicle:
1. Board the passenger using a wheelchair into the vehicle.
NOTE:
For information on ramp deployment and
wheelchair loading procedures, see the Ramp section in this
manual.
2. Position the wheelchair so the occupant is facing forward,
then move the wheelchair closer to the front console,
making sure to keep the wheelchair in alignment with the
rear restraint tracks on the floor.
3. Install the rear retractors into the tracks by pushing the
locking mechanism into the track then sliding the retractor
into place. The lock release on top of the locking mecha-
nism can be pulled up to aid in sliding the mechanism
along the track.
NOTE:
The four retractors are interchangeable between
the front and back.
CAUTION: DO NOT leave the retractors in the tracks
when they are not being used.
REASON: There is a possibility of galvanic corrosion if
the retractors are left in the tracks. Retractor and tie-downs
should be properly stored in their pouch when not in use.
ALWAYS stow the restraints in a secure location when not in use.
REASON: Unsecured restraints could become a
dangerous projectile in a collision and cause serious injury or
death.
