Using Markers
57
Using the Marker Configuration menu
Using the Marker Configuration menu
Instead of setting markers individually from the button bar markers can also be configured
fast and easily via the Marker Config menu.
Changing the configuration:
1.
Press the Marker key.
2.
In the Button bar tap the Marker Conf. button.
 The Marker Config window opens showing the settings for each marker. The settings
can be changed in the Button bar.
3.
In the Markers tab of the Marker Config window, tap a marker from the list.
– or –
Tap Marker No. in the Button bar and select a marker from the dropdown list.
 The editable parameters are displayed in the Button bar.
4.
Tap a parameter in the Button bar and change it as needed.
5.
Select another tab to change further settings (see following topics).
6.
To close the Marker Config menu, press the Esc key or tap the header of the button bar.
Markers button bar
In the Markers button bar following settings are available:
Tab
Select tab in the Marker Config window.
Marker No.
Select a marker to be set.
Enabled
Enable / disable marker.
A disabled marker is not displayed, but all settings are
retained.
Type
Set marker type: M = Single marker, D = Delta marker.
Ref.
Referenced marker if marker is set to delta.
Trace
Trace which the marker refers to.
Freq. Link
Two markers can be linked via a fixed frequency.
Time Link
Two markers can be linked via a fixed time.
Functions
Assign a function to a marker.
M1 as ref.
for all Delta Markers
Set marker 1 as reference for all delta markers.
Reset all Markers
Reset all markers.
