Defining the stop behavior (Stop Mode)
The stop mode value changes the behavior of the measurement engine, after the Run key is
pressed.
•
Hold: Measurement continues in the background.
•
Stop: Measurement stops and runs again.
You can stop/hold the measurement using the Run key.
To change these parameters:
1.
Tap the toggle button to select Hold or Stop.
2.
Press the Esc key or tap the header to close the menu.
Selecting traces (Traces)
Here you can select which traces are to be displayed (see Glossary for further explanations):
•
+Pk
•
RMS
•
Avg
–
Short tap: Avg
–
Long tap: third detector -Pk, Avg, Smp
•
MxP
•
MxR
•
AvR
•
MnR
•
MxA
•
Enable All: Tap to select all traces
•
Disable All: Tap to deselect all traces
To select the traces to be displayed:
 You selected the desired view.
1.
Tap the Traces button.
2.
Tap a button to switch the trace On / Off.
3.
Tap the Enable All button to display all traces.
4.
Tap the Disable All button to hide all traces. At least the RMS trace remains on as
default.
5.
To set the Third Detector: Long tap the Avg button and select a trace from the dropdown
list.
6.
Press the Esc key to close the menu.
BACKGROUND
There are three main detectors which compress all spectra occurring in the
measurement time to one spectrum (per measurement time), whereby the third detector
can have different functions.
Basis Traces:
• Detector 1: +Pk (Plus Peak)
