Spectrogram View
99
Setting the stop frequency (Fstop)
1. Tap the Fstop button.
2.
Enter the required value and select a unit.
 The setting is accepted immediately and the dropdown list is closed.
Setting the step width (Fstep)
1. Long tap the Fstart button.
 The context menu opens.
2.
Tap the Fstep button.
3.
Enter the step width and select a unit.
 The menu is closed.
4.
Press the Esc key to close the context menu.
Setting the resolution / EMC bandwidth
(RBW / EBW)
Here you can do the following:
1.
Set the resolution bandwidth (RBW) or EMC bandwidth (EBW).
2.
Enable automatic setting of the resolution bandwidth (Auto RBW).
3.
Set the entry mode (RBW Entry).
4.
Select the filter type (Filter Type).
Normal and EMC filter types:
The normal filter types resolution bandwidth (RBW) or channel bandwidth (CBW) allows
you to select a narrow frequency range with the desired bandwidth from a wideband
spectrum and to suppress the remaining signal components.
In the task modes Spectrum (Scan) and RT Spectrum, it is possible to use EMC filters
instead of the normal filters. When using EMC filters the following bandwidths can be
selected: 10 Hz, 100 Hz, 200 Hz, 1 kHz, 9 kHz, 10 kHz, 100 kHz, 120 kHz, 1 MHz.
The available bandwidths also depend on the Fspan setting.
After selecting the filter type EMC, the text RBW or CBW is replaced everywhere in the
corresponding views by the text EBW.
Selecting the filter type
 You selected the desired view.
To select the filter type:
1.
Long tap the RBW / EBW button. (The displayed button label depends on the currently
selected filter type.)
 The context menu opens.
2.
Tap the Filter Type button to select Normal or EMC type.
3.
Press the Esc key to close the context menu.
