NCR 7197 II SERIES - Page 159

7197 Series II Owner’s Guide Chapter 6: Commands
August 2011
134
Value of n Remote Diagnostic Item Function
ASC Hex Dec
BE 190 Dot Failure
Information(-1 Warning
Dot) on tally, 3 digit
ASCII numeric
Clear Dot Failure Information(-1
Warning Dot) on tally to 0.
BF 191 Dot Failure
Information(-1 Warning
Dot) on tally, 3 digit
ASCII numeric
Return Dot Failure Information(-1
Warning Dot) on tally, a total of 5
bytes.
C0 192 Dot Failure
Information(0 Warning
Dot) on tally, 3 digit
ASCII numeric
Write to Flash Rom
max 999
C1 193 Dot Failure
Information(0 Warning
Dot) on tally, 3 digit
ASCII numeric
Write to Flash Rom and print on
receipt to verify
C2 194 Dot Failure
Information(0 Warning
Dot) on tally, 3 digit
ASCII numeric
Clear Dot Failure Information(0
Warning Dot) on tally to 0.
C3 195 Dot Failure
Information(0 Warning
Dot) on tally, 3 digit
ASCII numeric
Return Dot Failure Information(0
Warning Dot) on tally, a total of 5
bytes.
 Example:
 MSComm1.Output = Chr$(&H1D) & Chr$(&H49) & Chr$(&H40) & Chr$(n)

Transmit Status
ASCII: GS r n
Hexadecimal: 1D 72 n
Decimal:
29 114 n
Value of n:
1, 49 = printer status
2, 50 = cash drawer status
4, 52 = Flash Memory status
5, 53 = printer other status
