7197 Series II Owner’s Guide Chapter 6: Commands
August 2011
78
1D 0E Erase the Flash Memory 193
1D 0F Return Main Program Flash CRC 193
1D 10 n Erase Selected Flash Sector 194
1D 11 aL aH cL cH
d1…dn
Download to Active Flash Sector 195
1D FF Reboot the Printer 196
Comparison Chart
The following table details the list of commands whose behavior differs from the 7193 and
the 7197 Series II because of the physical differences of a 6 dots/mm head (7193) versus
an 8 dots/mm head (7197 Series II).
Command Description Difference between 7193 and 7197
Series II
configured in 7193 Emulation Mode.
15 n Feed n Dot Rows This command will move
the paper on the receipt in
n/203 inch steps instead of
n/152 inch steps.
16 n Add n Extra Dot Rows The dot rows will be
measured in n/203 inches
versus n/152 inches.
1B 20 n Set Right-Side Character
Spacing
This command sets the right
side spacing to “n”
horizontal motion units. By
default, these units are in
terms of 1/203 inches versus
1/152 inches.
1B 24 n1 n2 Set Absolute Starting Position For graphics commands, the
position is scaled to best
7193. In text mode, the
equivalent character position
is calculated.
1B 26 s c1 c2 n1 d1...nn
dn]
Define User-Defined
Character Set
Since the dots on the 7197
Series II print head are
smaller, user-defined
characters that were used on
the previous printer will
appear smaller on the 7197
Series II printer.
1B 2A m n1 n2 d1...dn Select Bit Image Mode In 7193 Emulation Mode,
graphics are scaled to best
match the size of the graphic
in the 7193 printer.
1B 33 n Set Line Spacing This command uses n in
terms of n/360 inches. Since
To Next Page
