7197 Service Manual Appendix C: Ordering Paper and Supplies
August 2011
216
Reliability
The numbers in the table refer to the Mean Cycle Between Failure (MCBF) for the items
indicated.
Thermal Receipt Printer
52 Million Lines
Electronics
1,800,000 On time Hours
Communications Card
(RS232/USB)
25,000,000 On Time Hours
Communications Card
(Ethernet)
11,000,000 On Time Hours
Knife
1 Million Cuts
Power Supply
200,000 On-time Hours
*Reliabilitystatisticsbasedonaveragesexhibitedunderlabconditionsanddonot
constituteawarranty.
Dimensions and Weight
Height
144.90 mm (6.1 Inches)
Height with Cover Open
234.50 mm (9.23 Inches)
Width
145.40 mm (5.7 Inches)
Depth
186.70 mm (7.35 Inches)
Weight
1.70 Kg (3.7 Pounds)
Density of Receipt Print Lines
When the receipt station prints high density print lines (graphics), it automatically slows
down to a rate slower than 902 lines per minute. High density print lines are defined as
lines with over 50% of the dots printing on the line (there are 576 total dot columns on the
print station).
Duty Cycle Restrictions (Printing Solid Blocks)
There are restrictions on the duty cycle because of the heat generated by the receipt
thermal print head when printing solid blocks (regardless of the length of the block in
relation to the print line). The restrictions are ambient temperature, the percentage of time
(measured against one minute) of continuous solid printing, and the amount of coverage.
Caution: When the duty cycle approches the limits shown in the table, the receipt print
head will heat up and shut down. This may damage the print head.
To avoid this problem, do one or a combination of the following:
1. Reduce the amount of coverage.
2. Reduce the time of continuous solid printing.
