Ethernet Interface (Ethernet Model)
The Ethernet interface uses either 10BASE-t, 100BASE-TX protocol. The Ethernet version of
the 7197 Series II offers the web configuration which configure the ethernet settings via
Internet browser. See “Communications Interface Settings” later in this book.
Protocol
Protocol
- Physical layer
10BASE-t, 100BASE-TX (IEEE802.3 Conforming)
Auto negotiation 10/100Mbps Full/Half Duplex
- Data link layer
CSMA/CD
- Network layer
IP, ICMP, ARP
- Transport layer
TCP, IP
- Application layer
- TCP SOCKET
Number of simultaneous sessions
(Number of connections that can print)
1
Port type TCP communication port for direct
printing
Port number 9100 (Default)
Maximum simultaneous connections 3 clients
TCP (RAW)
Time out 120 seconds
Port type TCP communication port by LPR
Port number 515
Maximum simultaneous connections 1 client
TCP (LPR)
Time out 120 seconds
Number of simultaneous sessions 1
Port type UDP communication port for Real
Time Command
Port number 3000 (Default)
- UDP SOCKET
Maximum simultaneous connections 1 client
SNMP version SNMP v1 (RFC1157) compliant
Transport protocol UDP/IP
MIB support Part of MIB-II (RFC1213)
Part of HOST Resource MIB
Part of Printer MIB
PDU support Get Request
Get Next Request
Set RequestGet Response
Trap
Port number of Server 161
- SNMP Agent
Port number for Trap transmit 162
Transport protocol UDP/IP
- DHCP Client
Items to acquire IP address
Subnet mask
Gateway address
HTTP version 1.1
- WEB Printer
Transport protocol TCP/IP
