Appendix A: Specifications
Printing Specifications
Thermal Receipt Station
Print head
Fixed
576 Print Elements
Direct Thermal
Fixed Head
Line of Dots
Character Cell
Standard: 13 x 24 Dots
Compressed: 10 x 24 Dots
Character Size
.0525" Wide by .092" High
Character Spacing
15.25 Characters per Inch (horizontal)
Character Pitch
15.6 Characters/Inch (Standard)
20.3 Characters/Inch (Compressed)
Columns (maximum)
For 80 mm paper:
44 Columns (Standard)
56 Columns (Compressed)
For 58 mm paper:
32 Columns (Standard)
42 Columns (Compressed)
Print Mode
Standard, Compressed, Double High, Double
Wide, Upside Down, Rotated, Underline,
Scalable, Bold, Superscript, Italic, Subscript
Resident Fonts
Code Page 437, 850, 852, 860, 863, 865, 858, 866,
1252, Katakana, 874, 862, 864, and Space page
Speed
5414 Lines / Minute (44 columns) maximum,
Depend on Line Spacing
Print Order
Descending
Line Spacing
7.52 Lines per Inch ( default )
8.47, 8.13, 7.81, 7.25, 7.00, 5.98 Lines /
Inch and variable lines per inch.
Slew Speed
12 Inches per Second
Print Zone
2.83 Inches Maximum
To Next Page
