User & Installation Maunal Software
4.2 UNCOMPLETED IRRIGATION
The Uncompleted Irrigation table provides information of irrigations that where started
but did not complete the irrigation due to a fault. To understand way an irrigation was
not completed it is advisable to cross-reference between this table and table
3.2
ALARM > HISTORY.
The Uncompleted Irrigation table consists of up to 200 lines.
UNCOMPLETED IRRIGATION
No.
Date Time Prog Vl. Run Dose Program Left
hh:mm No. No. No. Prog Qty. Qty.
1
2
3
4
27-Dec-03 10:03 1 2 2 2 2.000 0.780
28-Dec-03 15:04 93 1 1 1 1.000 0.810
28-Dec-03 15:05 92 3 1 2 2.000 0.590
28-Dec-03 15:08 2 4 1 2 2.000 0.620
Each raw includes information regarding when irrigation was stopped and entered the
uncompleted irrigations table.
• Date – date current line entered the uncompleted irrigation table.
• Time – time current line entered the uncompleted irrigation table.
• Prog. No. – indicated the program number.
• 92 – the program that entered the table was started manually.
• 93 – the relevant irrigation has entered the uncompleted irrigations table for
the second time (or more) consecutively.
• Vl. No. - indicates the associated valve. If a group of valves defined to irrigate
together where stopped, only the first valve is written but a ‘+’ sign is entered next
to it to indicate that there are more valves associated.
• The NMC-64 will attempt to complete the irrigations from current day (until
end day time) upon manual or automatic alarm reset.
• Valve column of irrigations that are to be completed will be highlighted.
• Valve column of irrigations that are currently being completed will be
blinking.
• Run No. – indicates the associated run time program.
• Dose Prog. – indicates the associated dosing program.
• Prog. Qty. – planned quantity according to run time program.
• Left Qty. – uncompleted quantity.
41
