Netafim NMC-64 User Manual

User & Installation manual Hardware
Hardware
General Specifications
Housing
Plastic housing with a screw on lid IP 66
Dimensions (LxWxH) 400x300x130
Ambient conditions
Operating temperature range 0ºC to + 60ºC
Storage temperature range -10ºC to + 70ºC
Power Supply
The power supply card receives line voltage (220 / 110VAC) and provides voltages for
various users:
• 12VDC to the CPU and relays.
• 5VDC to digital inputs, 3VDC to analog inputs, etc’.
• 24VAC to 24VAC output cards.
Specifications
Mains voltage single phase 230VAC / 110VAC
Mains frequency 50/60Hz Maximum power consumption 50VA
Mains voltage Minimum 200VAC Maximum 250VAC
Main Fuse 1A
Available power for peripheral equipment
24VAC 80VA / 3.2A
Primary fuse 1.25A
Thermal fuse 9A

Netafim NMC-64 Specifications

General

Brand	Netafim
Model	NMC-64
Category	Controller
Language	English
