NMC-64 Irrigation
8. INSTALLATION
8.1 DEVICE LAYOUT
Device layout screen enables to assign functions to each output (relay).
Place the cursor on the Function column, use the arrow keys to reach the relevant
line, press Enter, a list of choice including all available devices will appear, choose the
required device and confirm by pressing Enter. The cursor will jump to the No. column,
define the number of the device in the controller and press enter to confirm.
If you wish to define a few devices of the same type, lets say valves 1 to 10. simply
define the first one and press enter a few times until you reach the required amount.
The NMC-64 automatically continues with the same device until told otherwise or until
reaching the system limitation for that device.
DEVICE LAYOUT
Relay Function No.
1
2
3
4
5
6
7
8
9
10
11
12
21
22
23
24
VALVE
VALVE
VALVE
VALVE
VALVE
VALVE
AGITATOR
COOLING
FERT BOOST
FILTER
FILTER
FERT
FERT
MAIN
PUMP
ALARM
1
2
3
4
5
6
1
1
1
1
2
1
2
1
1
1
After making changes, be sure to exit and return again to check for errors.
The NMC-64 will delete and replace conflicting assignments with ‘---‘.
66
