NMC-64 Irrigation
24AVC Output Card
The NMC-64 consists of maximum 8 output cards, 5 of which can be 24VAC output
cards; each card consists of 8 outputs, in total maximum 40 outputs 24VAC.
The 24VAC output card is used to drive devices that require a 24VAC power supply.
The bottom row consists of the common connections and the upper row of the
outputs.
It is possible to connect the common of several devices to the same connector
nevertheless it is recommended to try and spread the commons in an even manner.
The 24VAC output card consists of surge and lightening protection circuits and doesn’t
need the addition of external protections under normal conditions.
Specifications
8-40 N.O. low power relay 24VAC Output 5 Amps
Maximum Output Changing Rate 0.4 Sec
24VAC output card connections
72
