User & Installation Maunal Software
The EC/pH columns will not be visible if EC/pH control is marked ‘No’ in
menu 7.7 DOSING CONFIGURATION.
1.4 CONDITION
Condition program enables to start and / or stop irrigation according to dry contacts.
CONDITION PROGRAM
#
From To Start Trigger Stop
hh:mm hh:mm Dry Cont. Type Dry Cont.
1
2
3
4
5
6
7
8
9
08:00 16:00 Dry Con 1 One Shot Dry Con 2
06:00 20:00 Dry Con 4 Multi Shot ------
09:00 18:00 Dry Con 1 Only If On ------
--:-- --:-- <NONE> One Shot <NONE>
--:-- --:-- <NONE> One Shot <NONE>
--:-- --:-- <NONE> One Shot <NONE>
--:-- --:-- <NONE> One Shot <NONE>
--:-- --:-- <NONE> One Shot <NONE>
--:-- --:-- <NONE> One Shot <NONE>
• From (hh:mm) – Set the start time of the condition program.
• To (hh:mm) – Set the end time of the condition program
The condition program will only be operative in the defined window of opportunity
(between start “From” to end “To” times). Each condition program can be operative
on different hours.
• Start Dry Con. – Set the dry contact number for starting the irrigation.
• Trigger Type – Choose one of three trigger types:
1. One Shot – if the Start Dry Contact is closed for more than 20 seconds the
associated irrigation program will be started. The contact must open and close
to initiate another irrigation.
2. Multi shot – if the Start Dry Contact is closed for more than 20 seconds the
associated irrigation program will be started. If the contact is still closed when
the irrigation has finished another irrigation will be initiated.
25
