Introduction to NetApp EF570 All-Flash Arrays:
Feature Overview with SANtricity 11.50.2
© 2019 NetApp, Inc. All Rights Reserved.
Support for RAID 0, 1 (10 for 4 drives or more), 5, 6, and DDP
Note: It is only possible to create RAID 3 volumes through the
CLI. For more information, search for “using the create volume
group wizard” in SANtricity System Manager online help.
Redundant, hot-swappable storage controllers, disks, and
power fan canisters
Mirrored data cache with battery-backed destage to flash
*See the Controller Host Interface Features section for details of the available feature pack SMIDs for
EF570 controllers.
See the Hardware Universe for current supported drive availability information and encryption capability by
drive capacity (FDE, FIPS) Controller Host Interface Features.
By default, the EF570 controller includes two Ethernet management ports that provide out-of-band
system management access and either two 16Gbps FC or 10Gbps iSCSI optical baseboard ports for host
connections. As a result, EF570 controllers are ordered as either FC base or iSCSI base. Optional host
interface ports can be added as indicated in Table 12. For the optional 32Gbps FC, 25Gbps iSCSI, and
12Gbps SAS HICs, any of the feature pack SMIDs (FP-SMID) can be used because those interfaces
don’t have multiple protocol choices. The 32Gbps FC HIC uses specific FP-SMIDs for NVMe/FC protocol.
The 100Gbps IB HIC has four IB protocols available on the E5700 100Gb IB HIC, including:
• iSER
• SRP
• NVMe/IB
• NVMe/RoCE
Table 12) Available FP-SMIDs for EF570 controllers.
Encryption-Enabled
FP-SMID
Encryption-Disabled
FP-SMID
Any or no HIC (IB =
iSER)
Any or no HIC (IB =
NVMe-oF)
