75Neural Capture
04 RETURN TO QUAD CORTEX
Position a microphone in front of the cabinet speaker and connect it to
the Quad Cortex’s INPUT 2.
If you are capturing an amplier without built-in speakers or just an
amp head, connect its SPEAKER OUTPUT to a Reactive Load Box.
Then, connect the Load Box’s OUTPUT to the Quad Cortex’s INPUT 2.
If you are capturing an overdrive pedal, connect its OUTPUT directly to
the Quad Cortex’s INPUT 2.
05 SETUP REVIEW
Once everything is connected correctly, tap to proceed with
creating your Neural Capture.
Some amplier heads feature a
DI Output. Connecting it directly
to Quad Cortex via TRS or XLR
is safe as long as the speaker
output remains connected to a
cabinet.
