3.5 Basic Operations
3-67 ZM2376
the multi-measurement, the OPEN, SHORT, and LOAD corrections are not disabled, and the
previous setting of enable/disable is held.
Format >> Format setting menu for LOAD correction
LOAD Standard format: Cp-D Current setting
0) Cp-D 1) Cs-D 2) Rp-Cp 3) Rs-Ls >NEXT Options (first page)
4) Rs-X 5) Z-θ <PREV Options (second page)
Select the format to use when setting the spot LOAD correction value or the spot LOAD standard
value with numeric values or displaying them.
If a setting is made or the EXIT operation is performed, one-previous menu comes back.
STD >> Spot LOAD standard value input menu
Example: Standard value for the Cp-D format
LOAD STD= Cp: +1.23456µF D: +234.56m Current value
±(0.0000p to 999999M) 1.00000kHz Available ranges
Spot LOAD correction frequency
Frequency when the correction or standard value is set or measured
If disabled, "---"
Enter the calibration value (exact value) of the standard.
Initially, the cursor exists on the previous value. When the previous value is input and entered with
the _ENTR_
key, the cursor moves to the next value, indicating that the next value can be input.
The cursor can be moved between previous and next values by pressing the _BS_ | [PREV] or
_EXP_ | [NEXT] key.
If a setting is made or the EXIT operation is performed, one-previous menu comes back.
