3.5 Basic Operations
3-68 ZM2376
Entry >> Spot LOAD correction value input menu
Correction value for the Cp-D format (example)
Co-LOAD=Cp: +1.02345µF D: +123.456m Current value
±(0.0001p to 999999M) 1.00000kHz Available ranges
Spot LOAD correction frequency
Set the value of the standard measured with all of the OPEN, SHORT, and LOAD corrections
disabled. Initially, the cursor exists on the previous value. When the previous value is input and
entered with the _ENTR_ key, the cursor moves to the next value, indicating that the next value
can be input. The cursor can be moved between previous and next values by pressing the _BS_ |
[PREV] or _EXP_ | [NEXT] key. If you specify an extreme value which ZM2376 cannot calculate,
an error occurs, and it cannot be set.
Perform the EXIT operation to return to one-previous menu.
If the spot LOAD correction value is set, the LOAD correction is disabled. To use the set
correction value, enable both the spot correction and the LOAD correction.
 Setting LOAD standard value with numeric values (Spot correction)
To use a known calibration value of a standard for the spot LOAD correction, specify the format and
then set the standard value in the spot LOAD correction menu.
_SHIFT_ + [LOAD] >> LOAD correction menu
LOAD Correction: OFF 100Hz - 1.0MHz
0) OFF 1) ON 2) Measure 3) SPOT >NEXT
SPOT >> Spot LOAD correction menu
SPOT Correction: OFF Format: Cp-D @LOAD
0) OFF 1) ON 2) Format 3) STD 4) Entry
Format >> Format setting menu for LOAD correction
LOAD Standard format: Cp-D
0) Cp-D 1) Cs-D 2) Rp-Cp 3) Rs-Ls >NEXT
STD >> Spot LOAD standard value input menu
LOAD STD= Cp: +1.23456µF D: +234.56m
±(0.0000p to 999999M) 1.00000kHz
