3.5 Basic Operations
3-69 ZM2376
Setting numeric values/Reading of LOAD correction value (Spot correction)
To use the pre-measured value of a standard as the spot LOAD correction value, specify the format
and then set the correction value in the spot LOAD correction menu.
It is also possible to read the correction value to fine tune it.
_SHIFT_
+ [LOAD] >> LOAD correction menu
LOAD Correction: OFF 100Hz - 1.0MHz
0) OFF 1) ON 2) Measure 3) SPOT >NEXT
SPOT >> Spot LOAD correction menu
SPOT Correction: OFF Format: Cp-D @LOAD
0) OFF 1) ON 2) Format 3) STD 4) Entry
Format >> Format setting menu for LOAD correction
LOAD Standard format: Cp-D
0) Cp-D 1) Cs-D 2) Rp-Cp 3) Rs-Ls >NEXT
Entry >> Spot LOAD correction value input menu
CO-LOAD= Cp: +1.02345µF D: +123.456m
±(0.0001p to 999999M) 1.00000kHz
If the entered value differs by 20% or more from the standard value, the warning message is
displayed as in the case of measuring the correction value.
