6.6 Performance Testing
6-11 ZM2376
Measurement frequency 1MHz, Measurement signal level 1Vrms, Cable length 0m
Measurement
range
Standard
(nominal
value)
Calibration value of
standard
A
Measured value
B
Difference
100×(B-A)/A
Specification
B-A
1k
100pF
C F
C F
C %
C ± 0.41 %
D
D
D
D ± 0.0041
100
1000pF
C F
C F
C %
C ± 0.22 %
D
D
D
D ± 0.0022
100kΩ
100kΩ
Z Ω
Z Ω
Z %
Z ± 2.9 %
θ °
θ °
θ °
θ ± 1.7 °
10kΩ
10kΩ
Z Ω
Z Ω
Z %
Z ± 1.0 %
θ °
θ °
θ °
θ ± 0.57 °
1kΩ
1kΩ
Z Ω
Z Ω
Z %
Z ± 0.37 %
θ °
θ °
θ °
θ ± 0.21 °
100Ω
100Ω
Z Ω
Z Ω
Z %
Z ± 0.20 %
θ °
θ °
θ °
θ ± 0.11 °
10Ω
10Ω
Z Ω
Z Ω
Z %
Z ± 0.37 %
θ °
θ °
θ °
θ ± 0.21 °
For the 100 and 1k ranges, either a standard resistor or a standard capacitor should be used for
the test.
Measurement frequency 5MHz, Measurement signal level 1Vrms, Cable length 0m
Measurement
range
Standard
(nominal
value)
Calibration value of
standard
A
Measured value
B
Difference
100×(B-A)/A
Specification
B-A
1kΩ
1kΩ
Z Ω
Z Ω
Z %
Z ± 1.8 %
θ °
θ °
θ °
θ ± 1.0 °
100Ω
100Ω
Z Ω
Z Ω
Z %
Z ± 1.6 %
θ °
θ °
θ °
θ ± 0.91 °
10Ω
10Ω
Z Ω
Z Ω
Z %
Z ± 2.3 %
θ °
θ °
θ °
θ ± 1.3 °
