2.1 Checking Before Use
2-5 ZM2376
 Major relevant products
Since the test fixture and test lead are not supplied, please purchase them additionally. Major test
fixtures and test leads which can be used with ZM2376 are shown below.
Model
name
Product name
Supplemental note
Frequency range
ZM2363
Test fixture
For lead components
4-terminal connection
DC - 10MHz
2324
4-terminal alligator clip
test leads
------
DC - 100kHz
2325AL
Kelvin clip
test leads
Large-sized clip
(replaceable clip)
DC - 100kHz
2325AM
Kelvin clip
test leads
Medium-sized clip
(replaceable clip)
DC - 100kHz
ZM2392
Kelvin clip
test leads
Simple type
DC - 20kHz
ZM2391
3-terminal alligator clip
test leads
Two signals, one shield
DC - 20kHz
2326A
Chip component test lead
Tweezers type
2-terminal connection
DC - 1.2MHz
ZM2394
Chip test fixture
For SMD & chip parts
2-terminal connection
DC - 2MHz
ZM2394H
Chip test fixture
For SMD & chip parts
2-terminal connection
DC - 30MHz
The models connected to the DUT with two terminals are affected by the contact resistance and its
variations. For a measurement of about 50Ω or less, it is recommended to evaluate the variation of
measured value due to the contact resistance before using the test fixture.
The information given here is as of the preparation of this Instruction Manual. Relevant products are
subject to change, abolition, or addition without notice. Be sure to contact NF Corporation or one of
our representatives for confirmation when ordering them.
