3.2 Display at Power “ON” and Initial Settings
3-9 ZM2376
Setting item
Parameter range
Initial value
INIT
*RST
Setting
memory
Resume
Primary parameter deviation
comparison reference value
(Common to deviation
display)
0
←
←


<Limit comparison >


Primary parameter limit
comparison
OFF|ON
OFF
←
←


Secondary parameter limit
comparison
OFF|ON
OFF
←
←


<Handler interface>


AUX BIN function
OFF|ON
OFF (Include)
←
←


Bin extension BIN10..14
OFF|ON
OFF
←
←


TRIG polarity
Positive|Negative
Positive
×
×
×
×
Setting/correction value
memory recall target
SPOT correction|
Partial settings
|Settings|
Correction values|Both
SPOT correction
←
←


Test mode
OFF|ON|ER
OFF
←
←


Test output
L|H (for each pin)
(Depending on
the pin)
←
←


<Beeper>


Sounding selection
OFF|ON
OFF
←
←


Sounding condition
FAIL|PASS
FAIL
←
←


<Auxiliary display>
Status|BINn-Limit|
Sec-Limit|P-S-REF|
I-V|Z-θ|List
Status
(BIN 1)
←
←


<Data transfer
format>
ASCII|Real (binary)
|Packed
ASCII
←
←
×
×
<Measured data buffer>


BUF1, BUF2 data
Primary parameter |
Secondary parameter
|None
None, None
←
←
×
×
BUF1, BUF2, BUF3 feed
Send|Not send
Not send
(All)
←
←
×
×
BUF1, BUF2, BUF3 size
1 to 200, 1 to 200,
1 to 1000
200,200,1000
←
←
×
×
<Key lock>
OFF|ON
OFF
←
←
×
×
<Interface>
(LAN is optional)


Type
USB|RS232|GPIB|LAN
USB
×
×
×

GPIB address
0 to 30
2
×
×
×

RS-232 bit rate
4800 to 230400
9600
×
×
×

RS-232 terminator
CR|LF|CR LF
CR LF
×
×
×

RS-232 handshake
OFF|SOFT|HARD
OFF
×
×
×

LAN IP address
0.0.0.0 to 255.255.255.255
192.168.0.1
×
×
×

LAN subnet mask
0.0.0.0 to 255.255.255.255
255.255.255.0
×
×
×

LAN default gateway
0.0.0.0 to 255.255.255.255
0.0.0.0
×
×
×

<Setting/correction value
memory>


Content
-
Empty
(no saving)
×
×
－
－
Recall target (at panel
operation)
Settings|Correction
values|Both
Setting
←
←








