3.3 Operation Tree
3-12 ZM2376
Operation Tree (2/4)
_AUTO/HOLD_: Measurement range Auto/Manual selection
_SHIFT_ + [RANGE]: { Measurement range setting menu }
Range selection
{ Minimum output impedance setting menu }
_SHIFT_ + [OPEN]: { OPEN correction menu }
Disabled / Enabled / Correction value measurement { Measurement stop menu }
{ Spot correction menu }
{ Format setting menu }
{ Correction value input menu }
{ Lower limit frequency setting menu }
{ Upper limit frequency setting menu }
_SHIFT_ + [SHORT]: { SHORT correction menu }
Disabled / Enabled / Correction value measurement { Measurement stop menu }
{ Spot correction menu }
{ Format setting menu }
{ Correction value input menu }
{ Lower limit frequency setting menu }
{ Upper limit frequency setting menu }
_SHIFT_ + [LOAD]: { LOAD correction menu }
Disabled / Enabled / Correction value measurement { Measurement stop menu }
/ Standard value measurement { Measurement stop menu }
{ Spot correction menu }
{ Format setting menu }
{ Standard value input menu }
{ Correction value input menu }
{ Lower limit frequency setting menu }
{ Upper limit frequency setting menu }
_SHIFT_ + [CABLE]: { Cable length correction menu }
_SHIFT_ + [CONTACT]: { Contact check setting menu }
{ Low capacitance check setting menu }
{ Low capacitance limit setting menu }
Continued
