3.3 Operation Tree
3-13 ZM2376
Operation Tree (3/4)
_SHIFT_ + [COMPRTR]: { Comparator setting menu }
Disabled / Enabled
{ Deviation comparison menu }
Format selection
{ Reference value setting menu }
Initialization
{ Upper / Lower limit value setting menu }
Comparison enabled, upper limit value, lower limit value
_SHIFT_ + [NO LIMIT]: Disabled setting (Don't care)
_SHIFT_ + [Pri/Sec]: Pri-Sec switch
[PREV]: Switch through all parameter values (reverse)
[NEXT]: Switch through all parameter values (forward)
_SHIFT_ + [HANDLER]: { Handler interface setting menu }
{ OUT OF BINS output setting menu }
{ Bin extension menu }
{ Trigger polarity setting menu }
{ Recall setting menu }
{ Test menu }
Continued
