Unidrive M Regen Design Guide 7
Issue Number: 4
EU Declaration of Conformity (including 2006 Machinery Directive)
This declaration is issued under the sole responsibility of the manufacturer. The object of the declaration is in conformity with the relevant Union
harmonization legislation. The declaration applies to the variable speed drive products shown below:
The model number may be followed by additional characters that do not affect the ratings.
This declaration relates to these products when used as a safety component of a machine. Only the Safe Torque Off function may be used
for a safety function of a machine. None of the other functions of the drive may be used to carry out a safety function.
These products fulfil all the relevant provisions of the Machinery Directive 2006/42/EC and the Electromagnetic Compatibility Directive (2014/30/EU).
EC type examination has been carried out by the following notified body:
TUV Rheinland Industrie Service GmbH
Am Grauen Stein
D-51105 Köln
Germany
Notified body identification number: 0035
The harmonized standards used are shown below:
EC type-examination certificate numbers:
01/205/5270.02/17 dated 2017-08-28
Person authorised to complete the technical file:
P Knight
Conformity Engineer
Newtown, Powys, UK
DoC authorised by:
IMPORTANT NOTICE
These electronic drive products are intended to be used with appropriate motors, controllers, electrical protection components and other
equipment to form complete end products or systems. It is the responsibility of the installer to ensure that the design of the complete
machine, including its safety-related control system, is carried out in accordance with the requirements of the Machinery Directive and any
other relevant legislation. The use of a safety-related drive in itself does not ensure the safety of the machine. Compliance with safety and
EMC regulations depends upon installing and configuring drives correctly, including using the specified input filters. The drive must be
installed only by professional installers who are familiar with requirements for safety and EMC. The assembler is responsible for ensuring
that the end product or system complies with all relevant laws in the country where it is to be used. For more information regarding Safe
Torque Off, refer to the Product Documentation.
Nidec Control Techniques Ltd, The Gro, Newtown, Powys, SY16 3BE. UK
Model No. Interpretation Nomenclature aaaa - bbc ddddde
aaaa Basic series
M600, M700, M701, M702, M708, M709, M751, M753, M754, F300, H300, E200, E300, HS70, HS71, HS72,
M000, RECT
bb Frame size 01, 02, 03, 04, 05, 06, 07, 08, 09, 10, 11
c Voltage rating 1 = 100 V, 2 = 200 V, 4 = 400 V, 5 = 575 V, 6 = 690 V
ddddd Current rating Example 01000 = 100 A
e Drive format
A = 6P Rectifier + Inverter (internal choke), D = Inverter, E = 6P Rectifier + Inverter (external choke),
T = 12P Rectifier + Inverter (external choke)
EN 61800-5-1:2016 Adjustable speed electrical power drive systems - Part 5-2: Safety requirements - Functional
EN 61800-5-1:2016
(in extracts)
Adjustable speed electrical power drive systems - Part 5-1: Safety requirements - Electrical, thermal and energy
EN 61800-3: 2004+A1:2012 Adjustable speed electrical power drive systems - Part 3: EMC requirements and specific test methods
EN ISO 13849-1:2015 Safety of Machinery, Safety-related parts of control systems, General principles for design
EN 62061:2005 + AC:2010
+ A1:2013 + A2:2015
Safety of machinery, Functional safety of safety related electrical, electronic and programmable electronic control
systems
IEC 61508 Parts 1 - 7:2010 Functional safety of electrical/ electronic/programmable electronic safety-related systems
Jonathan Holman-White
Director of R&D
Date: 17th May 2018
Place: Newtown, Powys, UK
