Unidrive M Regen Design Guide 303
Issue Number: 4
10.5 Electromagnetic compatibility (EMC)
This is a summary of the EMC performance of the drive. For full details, refer to the EMC Data Sheet which can be obtained from the supplier of the
drive.
Table 10-42 Immunity compliance
IEC 61800-3:2004 and EN 61800-3:2004+A1:2012
The 2004 revision of the standard uses different terminology to align the requirements of the standard better with the EC EMC Directive.
Power drive systems are categorized C1 to C4:
Note that category 4 is more restrictive than E2R, since the rated current of the PDS must exceed 400 A or the supply voltage exceed 1000 V, for the
complete PDS.
Standard Type of immunity Test specification Application Level
IEC 61000-4-2
EN 61000-4-2:2009
Electrostatic discharge
6 kV contact discharge
8 kV air discharge
Module enclosure
Level 3
(industrial)
IEC 61000-4-3
EN 61000-4-3:2006+A2:2010
Radio frequency radiated
field
10 V/m prior to modulation
80 - 1000 MHz
80 % AM (1 kHz) modulation
Module enclosure
Level 3
(industrial)
IEC 61000-4-4
EN 61000-4-4:2012
Fast transient burst
5/50 ns 2 kV transient at 5 kHz
repetition frequency via coupling clamp
Control lines
Level 4
(industrial harsh)
5/50 ns 2 kV transient at 5 kHz
repetition frequency by direct injection
Power lines
Level 3
(industrial)
IEC 61000-4-5
EN 61000-4-5:2014
Surges
Common mode 4 kV
1.2/50 ms waveshape
AC supply lines:
line to ground
Level 4
Differential mode
2 kV1.2/50 ms waveshape
AC supply lines:
line to line
Level 3
Lines to ground
Signal ports to ground
1
Level 2
IEC 61000-4-6
EN 61000-4-6:2014
Conducted radio
frequency
10V prior to modulation
0.15 - 80 MHz
80 % AM (1 kHz) modulation
Control and power lines
Level 3
(industrial)
IEC 61000-4-11
EN 61000-4-11:2004
Voltage dips and
interruptions
-30 % 10 ms
+60 % 100 ms
-60 % 1 s
<-95 % 5 s
AC power ports
IEC 61000-6-1
EN 61000-6-1:2007
Generic immunity standard for the residential, commercial and light
- industrial environment
Complies
IEC 61000-6-2
EN 61000-6-2:2005
Generic immunity standard for the industrial environment
Complies
IEC 61800-3
EN 61800-3:2004+A1:2012
Product standard for adjustable speed power drive systems
(immunity requirements)
Meets immunity requirements for first and
second environments
Category Definition Corresponding code used above
C1 Intended for use in the first or second environments R
C2
Not a plug-in or movable device, and intended for use in the first environment only
when installed by a professional, or in the second environment
I
C3 Intended for use in the second environment, not the first environment E2U
C4
Intended for use in the second environment in a system rated at over 400A, or in a
complex system.
E2R
