146 Unidrive M Regen Design Guide
Issue Number: 4
9 Parameters
This is a quick reference to all parameters in the drive showing units, ranges limits etc, with block diagrams to illustrate their function. Full descriptions
of the parameters can be found in the Parameter Reference Guide.
Table 9-1 Menu descriptions
* Only displayed when the option modules are installed.
Default abbreviations:
Standard default value (50 Hz AC supply frequency)
USA default value (60 Hz AC supply frequency)
In some cases, the function or range of a parameter is affected by the setting of another parameter. The information in the lists relates to the default
condition of any parameters affected in this way.
These advanced parameters are listed for reference purposes only. The lists in this chapter do not include sufficient
information for adjusting these parameters. Incorrect adjustment can affect the safety of the system, and damage the drive and
or external equipment. Before attempting to adjust any of these parameters, refer to the Parameter Reference Guide.
Menu Description
0 Commonly used basic set up parameters for quick / easy programming
3 Regen control
4 Current control
5 Regen status
6 Sequencer and clock
7 Analog I/O, Temperature monitoring
8 Regen digital I/O
9 Programmable logic, motorized pot, binary sum, timers and scope
10 Status and trips
11 Drive set-up and identification, serial communications
12 Threshold detectors and variable selectors
14 User PID controller
15 Option module slot 1 set-up menu
16 Option module slot 2 set-up menu
17 Option module slot 3 set-up menu
18 General option module application menu 1
19 General option module application menu 2
20 General option module application menu 3
22 Menu 0 set-up
23 Not allocated
28 Reserved menu
29 Reserved menu
30 Onboard user programming application menu
Slot 1 Slot 1 option menus*
Slot 2 Slot 2 option menus*
Slot 3 Slot 3 option menus*
WARNING

Nidec Unidrive M600 Series Specifications

General

Brand	Nidec
Model	Unidrive M600 Series
Category	DC Drives
Language	English
