Unidrive M Regen Design Guide 17
Issue Number: 4
3.3 Ratings
The continuous current ratings given are for maximum 40 °C (104 °F), 1000 m altitude and 3 kHz switching frequency. Output current derating has
been applied based on Regen and switching frequency filter inductor capability. Additional derating is required for higher switching frequencies,
ambient temperature >40 °C (104 °F) and high altitude. For further information, refer to Chapter 10 Technical data on page 276.
Table 3-1 200 V drive ratings (200 V to 240 V ±10 %)
* The internal EMC filter and negative DC terminal are not accessible on Unidrive M Frames 9E/T, 10E/T and 11E/T. These power formats are
therefore not suitable for Regen systems. Select 9A/D or 10D power formats only.
Model
Normal Duty Heavy Duty
Max cont
current
Nominal
power at
230 V
Motor
power at
230 V
Peak
current
Max cont
current
Peak
current
Nominal
power at
230 V
Motor
power at
230 V
AkWhp A A A kW hp
03200066 8 1.5 2 8.8 6.6 13.2 1.1 1.5
03200080 11 2.2 3 12.1 8 16 1.5 2
03200106 11 3 3 13.9 10.6 19.2 2.2 3
04200137 15.5 4 5 19.8 13.7 27.1 3 3
04200185 22 5.5 7.5 27.5 15.5 27.1 4 5
05200250 30 7.5 10 33 22 38.5 5.5 7.5
06200330 50 11 15 55 31 54.2 7.5 10
06200440 56 15 20 63.8 42 73.5 11 15
07200610 75 18.5 25 82.5 56 98 15 20
07200750 94 22 30 103.4 75 140 18.5 25
07200830 105 30 40 128.7 80 140 22 30
08201160 149 37 50 163.9 105 183.7 30 40
08201320 180 45 60 198 132 264 37 50
09201760* 192 55 75 237.6 176 308 45 60
09202190* 250 75 100 292.6 192 336 55 75
10202830* 312 90 125 357.5 283 495.3 75 100
10203000* 350 110 150 396 300 525 90 125
