152 Unidrive M Regen Design Guide
Issue Number: 4
9.2 Menu 0: Basic parameters
Table 9-4 Unidrive M Regen menu 0 parameter descriptions
* Not available on Unidrive M700.
Parameter Range() Default()Type
00.001 Voltage Set Point {03.005} 0 to VM_DC_VOLTAGE_SET V
200 V: 350 Vdc
400 V: 700 Vdc
575 V: 835 Vdc
690 V: 1100 Vdc
RW Num RA US
00.002 Voltage Controller Proportional Gain Kp {03.006} 0 to 65535 4000 RW Num US
00.003 Synchronized {03.009} Off (0) or On (1)
RO Bit ND NC PT
00.004 Voltage Set Point {03.005} 0 to VM_DC_VOLTAGE_SET V
200 V: 350 Vdc
400 V: 700 Vdc
575 V: 835 Vdc
690 V: 1100 Vdc
RW Num RA US
00.005 Output Voltage {05.002} 0 to VM_AC_VOLTAGE V
RO Num ND NC PT
00.006 Not used
00.007 Regen Synchronization Mode {03.004}
Re-synchronize (0), Delayed Trip (1), Trip (2),
Auto-synchronize (3)
Re-synchronize (0) RW Txt US
00.008 Disable Charge System / Close Contactor {03.007} Off (0) or On (1)
RO Bit ND NC PT
00.009 Charge System Disabled / Contactor Closed {03.008} Off (0) or On (1)
RO Bit ND NC
00.010 Power Input 1 {03.010} ±100.0 % 0.0 % RW Num NC
00.011 Output Frequency {05.001} ±200.0 Hz
RO Num ND NC PT
00.012 Current Magnitude {04.001} 0 to VM_DRIVE_CURRENT_UNIPOLAR A
RO Num ND NC PT
00.013 Active Current {04.002} VM_DRIVE_CURRENT A
RO Num ND NC PT
00.014 Output Power {05.003}VM_POWERkW
RO Num ND NC PT
00.015 Reactive Power {03.001}VM_POWERkVAr
RO Num ND NC PT
00.016 Not used
00.017 Reactive Current Reference {04.008} VM_REGEN_REACTIVE % 0.0 % RW Num US
00.018 Not used
00.019 T7 Analog Input 2 Mode {07.011}
4-20mA Low (-4), 20-4mA Low (-3),
4-20mA Hold (-2), 20-4mA Hold (-1),
0-20mA (0), 20-0mA (1), 4-20mA Trip (2),
20-4mA Trip (3), 4-20mA (4), 20-4mA (5), Volt (6)
Volt (6) RW Txt US
00.020 T7 Analog Input 2 Destination {07.014} 0.000 to 59.999 3.010 RW Num DE PT US
00.021 T8 Analog Input 3 Mode {07.015}
Volt (6), Therm Short Cct (7), Thermistor (8),
Therm No trip (9)
Volt (6) RW Txt US
00.022
to
00.028
Not used
00.029 NV Media Card File Previously Loaded {11.036} 0 to 999 0 RO Num NC PT
00.030 Parameter Cloning {11.042} None (0), Read (1), Program (2), Auto (3), Boot (4) None (0) RW Txt NC
00.031 Drive Rated Voltage {11.033} 200V (0), 400V (1), 575V (2), 690V (3)
RO Txt ND NC PT
00.032 Maximum Heavy Duty Rating {11.032} 0.000 to 99999.999 A
RO Num ND NC PT
00.033 Not used
00.034 User Security Code {11.030} 0 to 2147483647 0 RW Num ND NC PT US
00.035 Serial Mode* {11.024}
8 2 NP (0), 8 1 NP (1), 8 1 EP (2), 8 1 OP (3),
8 2 NP M (4), 8 1 NP M (5), 8 1 EP M (6),
8 1 OP M (7), 7 2 NP (8), 7 1 NP (9),
7 1 EP (10), 7 1 OP (11), 7 2 NP M (12),
7 1 NP M (13), 7 1 EP M (14), 7 1 OP M (15)
8 2 NP (0) RW Txt US
00.036 Serial Baud Rate* {11.025}
300 (0), 600 (1), 1200 (2), 2400 (3), 4800 (4),
9600 (5), 19200 (6), 38400 (7), 57600 (8),
76800 (9), 115200 (10)
19200 (6) RW Txt US
00.037 Serial Address {11.023} 1 to 247 1 RW Num US
00.038 Current Controller Kp Gain {04.013} 0 to 30,000 90 RW Num US
00.039 Current Controller Ki Gain {04.014} 0 to 30,000 2,000 RW Num US
00.040 Not used
00.041 Maximum Switching Frequency {05.018}
3 (1) kHz, 4 (2) kHz, 6 (3) kHz, 8 (4) kHz,
12 (5) kHz, 16 (6) kHz
3 (1) kHz RW Txt RA US
00.042 Not used
00.043 Not used
00.044 Not used
00.045 Inductor Thermal Time Constant {04.015} 1.0 to 3000.0 89.0 RW Num US
00.046 Rated Current {05.007} 0.000 to VM_RATED_CURRENT A
Maximum Heavy Duty Rating
(Pr 00.032 {11.032}) A
RW Num RA US
00.047 Not used
00.048 User Drive Mode {11.031} Open-loop (1), RFC-A (2), RFC-S (3), Regen (4) Regen (4) RW Txt ND NC PT
00.049 User Security Status {11.044}
Menu 0 (0), All Menus (1), Read-only Menu 0 (2),
Read-only (3), Status Only (4), No Access (5)
Menu 0 (0) RW Txt ND PT
00.050 Software Version {11.029} 0 to 99999999
RO Num ND NC PT
00.051 Action On Trip Detection {10.037} 00000 to 11111 00000 RW Bin US
00.052 Reset Serial Communications* {11.020} Off (0) or On (1) Off (0) RW Bit ND NC
RW Read / Write RO Read only Num Number parameter Bit Bit parameter Txt Text string Bin Binary parameter FI Filtered
ND No default value NC Not copied PT Protected parameter RA Rating dependent US User save PS Power-down save DE Destination
