222 Unidrive M Regen Design Guide
Issue Number: 4
9.10 Menu 10: Status and trips
Table 9-13 Menu 10 Regen parameter descriptions
Parameter Range Default Type
10.001 Drive Healthy Off (0) or On (1) RO Bit ND NC PT
10.002 Drive Active Off (0) or On (1) RO Bit ND NC PT
10.008 Rated Load Reached Off (0) or On (1) RO Bit ND NC PT
10.009 Current Limit Active Off (0) or On (1) RO Bit ND NC PT
10.010 Regenerating Off (0) or On (1) RO Bit ND NC PT
10.011 Braking IGBT Active Off (0) or On (1) RO Bit ND NC PT
10.012 Braking Resistor Alarm Off (0) or On (1) RO Bit ND NC PT
10.015 Supply Loss Off (0) or On (1) RO Bit ND NC PT
10.016 Under Voltage Active Off (0) or On (1) RO Bit ND NC PT
10.017 Inductor Overload Alarm Off (0) or On (1) RO Bit ND NC PT
10.018 Drive Over-temperature Alarm Off (0) or On (1) RO Bit ND NC PT
10.019 Drive Warning Off (0) or On (1) RO Bit ND NC PT
10.020 Trip 0 0 to 255 RO Txt ND NC PT PS
10.021 Trip 1 0 to 255 RO Txt ND NC PT PS
10.022 Trip 2 0 to 255 RO Txt ND NC PT PS
10.023 Trip 3 0 to 255 RO Txt ND NC PT PS
10.024 Trip 4 0 to 255 RO Txt ND NC PT PS
10.025 Trip 5 0 to 255 RO Txt ND NC PT PS
10.026 Trip 6 0 to 255 RO Txt ND NC PT PS
10.027 Trip 7 0 to 255 RO Txt ND NC PT PS
10.028 Trip 8 0 to 255 RO Txt ND NC PT PS
10.029 Trip 9 0 to 255 RO Txt ND NC PT PS
10.030 Braking Resistor Rated Power 0.000 to 99999.999 kW See Table 9-14 RW Num US
10.031 Braking Resistor Thermal Time Constant 0.000 to 1500.000 s See Table 9-14 RW Num US
10.032 External Trip Off (0) or On (1) Off (0) RW Bit NC
10.033 Drive Reset Off (0) or On (1) Off (0) RW Bit NC
10.034 Number Of Auto-reset Attempts
None (0), 1 (1), 2 (2), 3 (3), 4 (4), 5 (5),
Infinite (6)
None (0) RW Txt US
10.035 Auto-reset Delay 1.0 to 600.0 s 1.0 s RW Num US
10.036 Auto-reset Hold Drive Healthy Off (0) or On (1) Off (0) RW Bit US
10.037 Action On Trip Detection 00000 to 11111 00000 RW Bin US
10.038 User Trip 0 to 255 RW Num ND NC
10.039 Braking Resistor Thermal Accumulator 0.0 to 100.0 % RO Num ND NC PT
10.040 Status Word 0 to 32767 RO Num ND NC PT
10.041 Trip 0 Date 00-00-00 to 31-12-99 RO Date ND NC PT PS
10.042 Trip 0 Time 00:00:00 to 23:59:59 RO Time ND NC PT PS
10.043 Trip 1 Date 00-00-00 to 31-12-99 RO Date ND NC PT PS
10.044 Trip 1 Time 00:00:00 to 23:59:59 RO Time ND NC PT PS
10.045 Trip 2 Date 00-00-00 to 31-12-99 RO Date ND NC PT PS
10.046 Trip 2 Time 00:00:00 to 23:59:59 RO Time ND NC PT PS
10.047 Trip 3 Date 00-00-00 to 31-12-99 RO Date ND NC PT PS
10.048 Trip 3 Time 00:00:00 to 23:59:59 RO Time ND NC PT PS
10.049 Trip 4 Date 00-00-00 to 31-12-99 RO Date ND NC PT PS
10.050 Trip 4 Time 00:00:00 to 23:59:59 RO Time ND NC PT PS
10.051 Trip 5 Date 00-00-00 to 31-12-99 RO Date ND NC PT PS
10.052 Trip 5 Time 00:00:00 to 23:59:59 RO Time ND NC PT PS
10.053 Trip 6 Date 00-00-00 to 31-12-99 RO Date ND NC PT PS
10.054 Trip 6 Time 00:00:00 to 23:59:59 RO Time ND NC PT PS
10.055 Trip 7 Date 00-00-00 to 31-12-99 RO Date ND NC PT PS
10.056 Trip 7 Time 00:00:00 to 23:59:59 RO Time ND NC PT PS
10.057 Trip 8 Date 00-00-00 to 31-12-99 RO Date ND NC PT PS
10.058 Trip 8 Time 00:00:00 to 23:59:59 RO Time ND NC PT PS
10.059 Trip 9 Date 00-00-00 to 31-12-99 RO Date ND NC PT PS
10.060 Trip 9 Time 00:00:00 to 23:59:59 RO Time ND NC PT PS
10.061 Braking Resistor Resistance 0.00 to 10000.00  See Table 9-14 RW Num US
10.063 Local Keypad Battery Low Off (0) or On (1) RO Bit ND NC PT
10.064 Remote Keypad Battery Low Off (0) or On (1) RO Bit ND NC PT
10.067 Fire Mode Active Off (0) or On (1) RO Bit ND NC PT
