306 Unidrive M Regen Design Guide
Issue Number: 4
Table 10-46 Optional external EMC Filter terminal data
10.5.2 Varistors
AC line voltage transients can typically be caused by the switching of large items of plant, or by lightening strikes on another part of the supply
network. If these transients are not suppressed, they can cause damage to the insulation of the Regen inductors, or to the Regen drive electronics.
Varistors should be fitted after the supply fuses and before the EMC filter as shown in the following.
Table 10-47 Varistors
Suitable DIN rail mounted surge protectors are also available from CITEL (DS40 series).
10.6 Combined Regen input filters (combi filter)
Table 10-48 Combi filter selection
* Output current derating must be applied based on Regen inductor and combi filter capability.
Part number
Power connections Ground connections
Max cable size /
Bar hole diameter
Max torque Ground stud size Max torque
4200-0272 16 mm² (6 AWG) 1.8 N m (15.9 Ib in) M6 5.0 N m (44.3 lb in)
4200-3230
4 mm² (12 AWG) 0.8 N m (7.1 Ib in) M5 2.5 N m (22.1 lb in)
4200-3480
4200-0122
16 mm² (6 AWG)
2.3 N m (20.4 lb in)
M6 5.0 N m (44.3 lb in)
4200-0312
1.8 N m (15.9 Ib in)
4200-0402
4200-2300
2.3 N m (20.4 lb in)4200-4800
4200-3690
4200-1132
50 mm² (1/0 AWG) 8.0 N m (70.9 lb in)
M10 18 N m (159.4 lb in)
4200-0672
4200-1972
95 mm² (3/0 AWG) 20 N m (177.1 lb in)
4200-1662
4200-3021
10.8 mm
30 N m (265.7 lb in)
4200-1660
4200-4460
11 mm
4200-2210
4200-0400
10.5 mm M12 25 N m (221.4 lb in)
4200-0690
Drive rating
Varistor voltage
rating V
RMS
Energy
rating
J
Quantity per
system
Configuration Part number
200 V
(200 V to 240 V±10 %)
550 620 3 Line to line 2482-3291
680 760 3 Line to ground 2482-3211
400 V
(380 V to 480 V±10 %)
550 620 3 Line to line 2482-3291
680 760 3 Line to ground 2482-3211
575 V
(500 V to 575 V±10 %)
680 760 3 Line to line 2482-3211
1000 1200 3 Line to ground 2482-3218
690 V
(690 V±10 %)
385 550 6 2 in series line to line 2482-3262
1000 1200 3 Line to ground 2482-3218
Model
Schaffner model number
Current rating
Heavy duty Normal duty A
07400660 & 07400770 06400470 & 07400660 FS6085-83-35-2 83
07401000 & 08401340* 07400770 & 07401000 FS6085-125-35-2 125
08401570 08401340 FS6085-168-40-2 168
09402000 & 09402240* 08401570 & 09402000* FS6085-205-40-2 205
10402700 & 10403200* 09402240 & 10402700* FS6085-300-99-2 300
10403200* FS6085-350-99-2 350
10601780 10601500 & 10601780 FS6085HV-200-40-2 200
