Table 10-44 Optional external EMC filter details
* At 55 °C (131 °F).
Table 10-45 Optional external EMC filter dimensions
Part number
Maximum continuous
current
Voltage rating
IP
rating
Power dissipation at
rated current
Ground leakage
Discharge
resistors
Balanced
supply phase-
to-phase and
phase-to-
ground
Worst case@ 40 °C
(104 °F)
@ 50 °C
(122 °F)
IEC UL
@ 40 °C
(104 °F)
@ 50 °C
(122 °F)
A A V V W W mA mA M
4200-3230 20 18.5 250 300
20
20 17 2.4 60
1.68
4200-0272 27 24.8 250 300 33 28 6.8 137
4200-0312 31 28.5 250 300 20 17 2.0 80
4200-2300 55 51 250 300 41 35 4.2 69
4200-1132 117 102.7* 528 480 50 43.7 11.7 188
4200-1972 197 172.8* 528 480 42 36.7 18.7 210
4200-3021 302 277 528 480
00
34 29.7 30 202
4200-4460 446 409 528 480 37 32.4 30 283
4200-3480 16 15 528 600
20
13 11 10.7 151
4200-0252 25 23 528 600 28 24 11.1 182
4200-0402 40 36.8 528 600 47 40 18.7 197
4200-4800 63 58 528 600 54 46 11.2 183
4200-0400 685 551 480 480 00 44 38.5 60.7 275
4200-3690 42 39 760 600
20
45 39 12 234
4200-0672 67 58.8* 759 600 25 21.9 24.5 395
2.72
4200-1662 114 100* 759 600 39 34.1 24.3 364
4200-1660 166 152 759 600
00
13 11.4 21 332
4200-2210 221 203 759 600 16 14 21 434
4200-0690 403 368 690 N/A 28 24.5 25 583
Part number
Dimension
Weight
HW D
mm inch mm inch mm inch kg lb
4200-3230 426 16.77 83 3.27 41 1.61 1.9 4.20
4200-0272 437 17.20 123 4.84 60 2.36 4.0 8.82
4200-0312 437 17.20 143 5.63 60 2.36 5.5 12.13
4200-2300 434 17.09 210 8.27 60 2.36 6.5 14.30
4200-1132 270 10.63 90 3.54 150 5.90 6 13.2
4200-1972 300 11.81 120 4.72 170 6.69 9.6 21.2
4200-3021 339 13.3 230 9.06 120 4.72 11 24.3
4200-4460 105 4.13 360 14.2 245 9.6 12 26.5
4200-3480 426 16.77 83 3.27 41 1.61 2.0 4.40
4200-0252 437 17.20 123 4.84 60 2.36 4.1 9.04
4200-0402 437 17.20 143 5.63 60 2.36 5.5 12.13
4200-4800 434 17.09 210 8.27 60 2.36 6.7 14.80
4200-0400 135 5.32 386 15.2 260 10.2 14.7 32.41
4200-3690 434 17.09 210 8.27 60 2.36 7.0 15.40
4200-0672 270 10.63 90 3.54 150 5.90 6.2 13.7
4200-1662 300 11.81 120 4.72 170 6.69 9.4 20.7
4200-1660 360 14.2 245 9.6 105 4.13 5.2 11.5
4200-2210 105 4.13 360 14.2 245 9.6 10.3 22.7
4200-0690 135 5.32 386 15.2 260 10.2 16.75 36.9
