276 Unidrive M Regen Design Guide
Issue Number: 4
10 Technical data
10.1 Drive
10.1.1 Power and current ratings (Derating for switching frequency and temperature)
Output current derating has been applied based on Regen and switching frequency filter inductor capability
Table 10-1 Maximum permissible continuous output current @ 40 °C (104 °F) ambient
Model
Normal Duty Heavy Duty
Nominal
rating
Maximum permissible continuous output current
(A) for the following switching frequencies
Nominal rating
Maximum permissible continuous output current
(A) for the following switching frequencies
kW hp 3 kHz 4 kHz 6 kHz 8 kHz 12 kHz 16 kHz kW hp 3 kHz 4 kHz 6 kHz 8 kHz 12 kHz 16 kHz
200 V
03200066 1.5 2.0 8.0 1.1 1.5 6.6
03200080 2.2 3.0 11 10.2 1.5 2.0 8.0 7.5
03200106 3.0 3.0 11 10.2 2.2 3.0 10.6 8.8 7.5
04200137 4.0 5.0 15.5 3.0 3.0 13.7
04200185 5.5 7.5 22 4.0 5.0 15.5
05200250 7.5 10 30 27.6 23.7 5.5 7.5 22 21.5 18.8
06200330 11 15 50 42.3 24.5 7.5 10 31 27
06200440 15 20 56 53 42.3 32.5 11 15 42 40 33 27.3
07200610 18.5 25 75 74.3 59.7 15 20 56 53.1
07200750 22 30 94 74.3 59.7 18.5 25 75 65.3 53.1
07200830 30 40 105 96 74.3 59.7 22 30 80 65.6 53.1
08201160 37 50 149 146 125.2 93 30 40 105 103 89.3 80.5
08201320 45 60 180 160.2 148.8 126 93 37 50 132 126.7 114 103 89.8 80.5
09201760 55 75 192 184 128 93 45 60 176 153 110 81
09202190 75 100 250 218 184 128 93 55 75 192 180 153 110 81
10202830 90 125 312 266 194 144 75 100 283 264 228 170 127
10203000 110 150 350 313 266 194 144 90 125 300 264 228 171 129
400 V
03400078 4.0 5.0 9.5 7.6 5.7 3.0 5.0 7.8 7.6 5.7 4.4
03400100 5.5 7.5 12 10.5 7.6 5.8 4.0 5.0 9.5 9.2 7.7 5.7 4.4
04400150 7.5 10 16 14.6 11.1 5.5 10 15.0 14.4 11.5 9.4
04400172 11 15 24 21.8 19.2 14.6 11.2 7.5 10 16 14.4 11.5 9.4
05400270 15 20 30 25.8 22.2 17.1 13.5 11 20 25.4 23.7 20.3 17.6 13.8 11.1
05400300 15 20 31 30.7 26.4 18.3 14.1 15 20 30 27.9 24 21 14.9 12.2
06400350 18.5 25 38 31 24.3 15 25 34 30 23 18.5
06400420 22 30 46 41 31 24.5 18.5 30 40 35 30 23 18.5
06400470 30 40 60 57 48 41 31 24.5 22 30 46 42 35 30 23 18.5
07400660 37 50 70 63 53.6 30 50 66 57 48 41 34
07400770 45 60 94 80.6 63 53.6 37 60 70 59 51 44 37
07401000 55 75 112 95.2 80.6 63 53.8 45 75 96 88 73 61 48 41
08401340 75 100 155 132 98 77 55 100 124 130 109 91 72 57
08401570 90 125 180 169 142 106.7 77 75 125 156 143 121 104 80.1 65
09402000 110 150 200 192 159 108 77 90 150 180 157 130 92 65
09402240 132 200 255 231 192 160 109 77 110 150 200 190 157 130 92 65
10402700 160 250 300 285 238 173 124 132 200 270 237 200 147 108
10403200 200 300 350 339 285 238 173 126 160 250 300 282 237 202 147 109
