Unidrive M Regen Design Guide 277
Issue Number: 4
11403770 225 350 437 415 336 272 185 300 377 372 296 245
11404170 250 400 460 415 336 272 200 350 415 372 296 245
11404640 280 400 460 415 336 272 250 400 415 372 296 245
575 V
06500150 11.0 15.0 17 14.8 7.5 10 15 11.6
06500190 15.0 20.0 22 20.5 15 11 15 19 15.4 11.6
06500230 18.5 25.0 27 26.2 20 16 15 20 22 20 15.4 12.8
06500290 22.0 30.0 34 31 26.2 20 16.8 18.5 25 27 23.8 20 15.4 12.8
06500350 30.0 40.0 43 39.6 31 26.2 20 16.8 22 30 34 29.8 23.8 20 15.4 13
07500440 45 50 52 51.8 40.2 27.7 21.2 30 40 43 39.2 30.8 21.6 16.7
07500550 55 60 63 51.8 40.2 27.7 21.2 37 50 52 39.2 30.8 21.6 17.1
08500630 75 75 85 73.1 49.7 37.8 45 60 63 53.3 37.2 28.4
08500860 90 100 100 91.8 73.1 49.7 37.8 55 75 85 67.1 53.3 37.8 28.4
09501040 110 125 125 101 71 54 75 100 100 85 61 47
09501310 110 150 144 126 100 70 54 90 125 125 106 85 61 47
10501520 130 200 192 168 126 100 70 54 110 150 144 138 106 85 61 47
10501900 150 200 192 152 116 76 54 132 200 190 186 137 106 70 51
11502000 185 250 248 220
150 200 200 184
11502540 225 300 265 220 185 250 221 184
11502850 250 350 265 220 225 300 221 184
690 V
07600190 18.5 25 22 21.2 15 20 19 16.7
07600240 22 30 27 27.9 21.2 18.5 25 22 21.8 16.6
07600290 30 40 36 28.1 21.2 22 30 27 21.8 16.5
07600380 37 50 43 40.5 28.1 21.2 30 40 36 30.8 21.7 16.7
07600440 45 60 52 51.5 40.6 28.1 21.2 37 50 43 38.7 30.8 21.6 16.7
07600540 55 75 63 51.8 40.6 28.1 21.2 45 60 52 39 31 21.6 16.7
08600630 75 100 85 72.2 49.7 37.8 55 75 63 53.3 37 28.4
08600860 90 125 100 91.8 72.4 49.7 37.8 75 100 85 67.1 53.3 37 28.4
09601040 110 150 125 100 71 54 90 125 100 85 61 47
09601310 132 175 144 126 100 71 54 110 150 125 105 85 62 47
10601500 160 200 168 169 126 100 71 55 132 175 144 138 105 86 62 47
10601780 185 250 192 154 114 75 55 160 200 168 137 105 69 52
11602100 200 250 225 220
185 250 210 184
11602380 250 300 265 220 200 250 221 184
11602630 280 400 265 220 250 300 221 184
Model
Normal Duty Heavy Duty
Nominal
rating
Maximum permissible continuous output current
(A) for the following switching frequencies
Nominal rating
Maximum permissible continuous output current
(A) for the following switching frequencies
kW hp 3 kHz 4 kHz 6 kHz 8 kHz 12 kHz 16 kHz kW hp 3 kHz 4 kHz 6 kHz 8 kHz 12 kHz 16 kHz
