Nikon D3100 VBA28001 - Page 78

VBA28001-R.3813.A
- A19 ・ D3100 -
TA-0026 (5×40)
Black : 4.0cm
Red : 4.5cm
Black : 6.7cm
Red : 6.2cm
Attach the double-stick tape [TA-0026 (5×40)] to the bottom plate (#61), and attach the two wires of the
condenser on the tape.
•
Attaching position
Dent here.
