Items Judgment standard Remarks
Viewfinder
Inner LCD lower
panel window position
Finder eld frame
Field of viewnder
(frame covage)
Parallax
(Difference of center
from the shot image/
sensor)
Up-down position: 0.5 - 1.25a (a= LCD width) from the nder
eld frame
Tilt: 1°or less
Tilt: (Right-left tilt from the lower part of nder eld frame):
30’ or less
Relative angle to image sensor: 30’or less
In height and width: 95 %
Up-down: 0.5 mm or less
Right-left: 0.5 mm or less
Visual check
Shoot the finder
field frame with
the 0.2-mm-or-less
tilt of optical axis
from the viewfinder
eyepiece optical
axis, and measure
the angle.
AF50/1.4D, F5.6
Measure a difference
in the center btwn
the marked finder
field and actual shot
object.
Eye point Distance to eyepiece protective glass: 19.5 ± 10％ Eye point tool
Vernier caliper
Battery life
EN-EL3e
+3
-2
General mode
Room temperature: 500 frames or more
0℃ : 400 frames or more
・Setting ISO100, Exposure mode: M, 1/250 sec., F16, AF-C, operation mode: S, Panasonic RP-SDK512J1A,
Illuminated surface: LV12, Image quality: NORM, Image size: L, White balance: A,
Halfway press→ Card format → Repeat the below “Operation” → Remove the card when the no. of
exposures remaining becomes “0” → Card format →…
・Lens: AF-S DX ED18-70/3.5-4.5G(IF)
・Operation: Repeat the following the odd-numbered shots and even-numbered shots until the number of exposures
remaining becomes "0". Switch power OFF for 1 min. each time 10 frames are shot.
Professional mode
Room temperature: 2500 frames or more
0℃ : : 1900 frames or more
・Setting ISO100, Exposure mode: M, 1/250 sec., F16, AF-C, operation mode: C, Panasonic RP-SDK512J1A,
Illuminated surface: LV12, Image quality: BASIC, Image size: M, White balance: A,
Halfway press→ Card format → Repeat the below “Operation” → Remove the card when the no. of
exposures remaining becomes “0” → Card format →…
・Lens:［AF-S DX18-135/3.5-5.6G］
・Operation: Halfway press for 3 sec. → AF-scan reciprocating motion 3 times → Continuous releases 6 times → TFT
playback for 5 sec.→ Half-release timer OFF waiting for 6 sec.
Shots Odd-numbered shots
Even-numbered shots
Repeat
operation
MENU ① - ⑤ .
① Halfway press 5 sec.
② AF scan reciprocating motion once
③ Release… Built-in SB full flash
④ TFT playback 5 sec.
⑤ Half-release timer OFF waiting 6 sec.
※ Activate the flash of AF-assist illuminator.
① Halfway press 5 sec.
② AF scan reciprocating motion once
③ Release… Built-in SB full flash
④ TFT playback 5 sec.
⑤ Half-release timer OFF waiting 6 sec.
※ Do NOT activate the flash of AF-assist illumi-
nator.
