Nilfisk-Advance BR 751 - User Manual

192 pages

Go to English

Save Page as PDF

To Next Page

BR 601 / BR 651

BR 751 / BR751 C

ITALIANO MANUALE DI ASSISTENZA

ENGLISH SERVICE MANUAL

909 6424 000(3)2007-12

Main Page

Questions and Answers

T
thomasowensAug 6, 2025
Why is no solution reaching the brush of my Nilfisk-Advance Floor Machine?
- B
  brittanyturnerAug 6, 2025
  If the solution isn't reaching the brush on your Nilfisk-Advance Floor Machine, several factors could be at play. Start by checking the solution filter for clogs and clean it if needed. Also, ensure the solution tap isn't closed or partially closed; if it is, replace it. A broken solenoid valve or an electrical connection issue could also be the culprit, in which case you should replace the valve or repair the connection. Finally, inspect the solution tank and hoses for any debris that might be obstructing the flow, and clean them accordingly.
M
Mary SmithAug 20, 2025
What to do if the solution reaches the brush of my Nilfisk-Advance Floor Machine even when it is off?
- E
  Eric SloanAug 20, 2025
  If the solution continues to flow to the brush of your Nilfisk-Advance Floor Machine even when the machine is turned off, it might be due to dirt or calcium deposits on the solenoid valve gasket, requiring a cleaning. Alternatively, the solenoid valve itself might be broken and need replacement.

Summary

GENERAL INFORMATION

Machine Lifting

Warning about supporting lifted machine with safety stands during work.

Safety

Information about symbols indicating dangerous situations and necessary precautions.

Technical Data

Contains specifications and technical details of the machine models.

Dimensions

Provides physical measurements for different machine models.

MAINTENANCE

Scheduled Maintenance

Information on regular maintenance for machine lifespan and safety.

Scheduled Maintenance Table

Table outlining maintenance procedures and their recommended intervals.

DETERGENT SUPPLY SYSTEM

Solution;Washing Water System and Tank Cleaning

Procedure for cleaning the solution/washing water system and its tank.

EDS - ECO DOSAGE SOLUTION

Detergent Tank Cleaning

Procedure for cleaning the detergent tank for the EDS - ECO Dosage Solution system.

Draining

Instructions on how to drain the EDS - ECO Dosage Solution from the system.

BRUSHING SYSTEM

Brush Motor Electrical Input Check

Procedure for checking the electrical input of brush motors, requiring qualified personnel.

RECOVERY WATER SYSTEM

Recovery Water Tank and Vacuum Grid Float Cleaning

Procedure to clean the recovery water tank and the vacuum grid with shut-off float.

Vacuum System Motor Electrical Input Check (before S;N)

Steps to check the electrical input of the vacuum system motor for specific serial number ranges.

Squeegee Cleaning;Check and Blade Replacement

Procedure for cleaning, checking, and replacing squeegee blades.

PARKING BRAKE SYSTEM

Parking Brake Check

Procedure to check the parking brake's functionality by manually pushing the machine.

DRIVE SYSTEM

Drive System Motor Electrical Input Check (Up to Jan 2007)

Procedure to check the electrical input of the drive system motor for machines made before Jan 2007.

Drive System Motor Electrical Input Check (After Jan 2007)

Procedure to check the electrical input of the drive system motor for machines made after Jan 2007.

ELECTRICAL SYSTEM

Fuse Check;Replacement

Troubleshooting

Addresses battery issues, charger faults, wiring harness problems, and electronic board error codes.

Function Electronic Board Connection Reference

Component Layout

Wiring Diagram

Schematic representation of the machine's electrical connections and circuits.
