SERVICE MANUAL
ENGLISH
BR 601 / BR 651 / BR 751 / BR 751 C 909 6424 000(3)2007-12
49
PARKING BRAKE SYSTEM
PARKING BRAKE SYSTEM
PARKING BRAKE CHECK
Lift the brushes and the squeegee, then drive the machine on a dry fl oor that offers a good grip.
Turn the ignition key (12) to "0".
Get off of the machine and push it manually in the direction shown by the arrow (A), then check that the front wheel (B) is
locked.
If necessary, replace the electromagnetic brake (see the procedure in the relevant paragraph).
B (*)
A
B (**)
S301640
(*) Machines up to January 2007
(**) Machines after January 2007
1.
2.
3.
