Questions and Answers

D
Donna WilliamsAug 15, 2025
What to do if Status LED is off or on continuously on NIRx All in One Printer?
- S
  Samantha DoughertyAug 15, 2025
  If the Status LED on your NIRx All in One Printer is off or continuously on, it could be due to a data connection problem. First, try reconnecting the USB cable. If that doesn't work, try using a different cable or USB port. Also, ensure that the necessary software and drivers are correctly installed on your computer. Finally, check the device's presence and function in the ‘National Instruments Automation Explorer.’ If the device is listed but inactive, remove it, restart your PC, and reconnect the NIRSport.
K
Kristine MccallAug 18, 2025
How to fix power LED when it does not light up on NIRx All in One Printer?
- Y
  Yvonne ReidAug 18, 2025
  If the Power LED on your NIRx All in One Printer isn't lighting up, the issue might be related to the power supply. First, make sure the power switch is turned on. Next, check that the AC line is properly connected. Lastly, inspect the fuses and replace them if needed.
V
Vincent SpencerAug 21, 2025
Why is the data from NIRx Measuring Instruments overly noisy?
- G
  grace64Aug 21, 2025
  If the NIRx Measuring Instruments show overly noisy data, it might be due to ambient light interference. Ensure the head is well shielded and not directly illuminated by ambient light, especially fluorescent tubes.
T
thomas25Aug 25, 2025
What to do if the status LED is off or on continuously on NIRx Measuring Instruments?
- H
  Heather WarnerAug 25, 2025
  If the status LED is off or continuously on, there might be no data connection to the PC. Try reconnecting the USB cable, using a different cable or port, and ensuring that the software and drivers are installed correctly.
A
Audrey HamiltonAug 27, 2025
What to do if all sources show maximum gain and low signal for the same detector channel on NIRx Measuring Instruments?
- J
  Joe BlackAug 27, 2025
  If all sources show maximum gain and low signal for the same detector channel on NIRx Measuring Instruments, it indicates a low signal from the detector. Check the optical coupling of the affected detector to the skin, part hair if needed, apply coupling gel, and apply gentle pressure through the outer cap or bandage. Also, check the connection of the affected fiber optic cable to the instrument.
K
Kevin OconnellAug 30, 2025
What to do if a large number of channels go to highest gain setting on NIRx Measuring Instruments?
- D
  Denise SellersAug 30, 2025
  If a large number of channels or all channels go to the highest gain setting on NIRx Measuring Instruments, it could indicate low or no signal in all channels. Check the connection of the LED POD, ensure the LEDs are blinking during scanning, verify the connection of the fiber optic bundles, check the proper placement of probes on the subject's head, and inspect for damage on the LED illuminator or fiber optic cable.
L
lorraine11Sep 2, 2025
What to do if NIRx Measuring Instruments show software error message 'Device may not be connected'?
- W
  William MillerSep 2, 2025
  If you encounter a software error message stating 'Device may not be connected' on NIRx Measuring Instruments, ensure that a USB connection is established and that the Status LED is blinking.
S
Shawn DuncanSep 5, 2025
What to do if all detectors show maximum gain for the same source on NIRx Measuring Instruments?
- J
  Jessica WallaceSep 5, 2025
  If all detectors show maximum gain for the same source on NIRx Measuring Instruments, it is likely due to a low signal from the source. Check the optical coupling of the affected source to the skin, part hair if needed, apply coupling gel, and apply gentle pressure through the outer cap or bandage.
M
Mrs. Laurie ScottSep 8, 2025
How to fix power LED if it does not light up on NIRx Measuring Instruments?
- A
  ahortonSep 8, 2025
  If the power LED does not light up on NIRx Measuring Instruments, it could be due to no power reaching the instrument. Check if the power switch is turned on, ensure the AC line is properly connected, and inspect the fuses, replacing them if necessary.
P
Patricia GonzalezSep 12, 2025
What to do if there is no or low reading for one source at one wavelength on NIRx Measuring Instruments?
- P
  Priscilla ButlerSep 12, 2025
  If there is no or low reading for one source at one wavelength on NIRx Measuring Instruments, it might be due to damage to the LED driver or LED optode. Restart the instrument, and without performing calibration, start a scan and point the affected LED directly into a detection fiber tip or detector channel port. If it's working correctly, there should be a stable reading for both wavelength plots in the scan screen (display set to raw data).

Summary

Installation Guide

System Requirements

Lists the necessary hardware and software configurations for NIRStar 14.1.

Software Setup

Guides the user through the installation process of NIRStar 14.1.

Hardware Configuration

Hardware Specification

Details how to configure hardware settings and identify the connected NIRS device.

Predefined Montages

Introduces quick setup using pre-defined hardware configurations.

Channel Setup

Explains how to define measurement channels and illumination sequences.

Operating Panel Functions

Calibrate Instrument

Procedure to set optimal gain for measurements and assess signal quality.

Preview Scan

Initiates a test scan without saving data for inspection.

Record Data

Initiates the actual data recording process for the experiment.

System Setup and Calibration

Signal Quality Assessment

Explains the 'traffic-light' classification of data quality for each channel.

Gain, Level, and Noise Displays

Accessing individual quality metrics like Gain, Level, and Noise.

Data Visualization and Recording

Trace Plot Display

Displays time-series data of estimated hemoglobin changes per channel.

Topographic Display

Presents data as 2D color maps representing spatial distribution.

Quick Start Guide

System Power-Up

Steps to correctly turn on all system components.

Initialize Measurement

Starts the calibration process to set gain and check setup.

Perform Scan

Initiates the data recording measurement.

Device-Specific Information

NIRSport Device Details

Information specific to the NIRSport NIRS imaging device.

Tandem Operation Mode

Describes operating two identical NIRx imagers simultaneously.

NIRx NIRSport Specifications

General

Type	Functional Near-Infrared Spectroscopy (fNIRS) System
Wavelengths	760 nm and 850 nm
Number of Sources	8
Number of Detectors	8
Sampling Rate	up to 7.81 Hz
Light Source	LED
Detectors	Silicon Photodiodes
Portability	Portable
Battery Life	Up to 8 hours
Software	NIRStar
Power	Rechargeable Battery
Data Acquisition	Continuous
Connectivity	USB
Compatibility	Windows, macOS
