The PRffffff.TXT named logging files in the directories consist of two main parts: header and data field. The header contains the following information:
NIVELCO DataLogger Ver.:1.08 MultiCONT Ver.:01.02.02 << DataLogger and MultiCONT version
Date:2001.01.01 01:02 << Date of file creation
Data field contains the following data rows:
Title
Description Example
Head Logging entry code (LG = logger, ST = status, SD = mem.card operation, ER = error message)
Date Logging entry date 2010.05.07
Time Logging entry time 13:01:40
Type Logging entry type (see Type codes) 2
Dev List-tag of the source device 3
Addr HART Long address of the transmitter 151.30.2555904
Tag Short tag SAP-300
Err. Error 0
Status Status 0
Curr1 FLOW
Value1 125.67
Unit1
Primary Value
m3/h
Curr2 LEV
Value2 0.567
Unit2
Selected additional 2
nd
quantity
m
Curr3 TOT2
Value3 12345678
Unit3
Selected additional 3
rd
quantity
m3
Curr4 Work
Value4 1548
Unit4
Selected additional 4
th
quantity
h
