Comments:
 If logging entry type is not 2, then MultiCONT is the source ( DEV=255, TAG=P-100, Error=0, Status=0), instead of the PV and the three additional selected
values use NAN (no data) caption can be read.
 Insertion of SD card: SD 2010.05.07 13:01:40 SD pushed
 Removal of SD card: SD 2010.05.07 13:01:40 SD pulled
 In case of ST entries, the selected values in LP1, LP2 and LP3 parameters can be read out from Value1, Value2 and Value3.
 In case of ST entries the following codes are in the Type and Dev columns:
Type:
B7 B6 B5 B4 B3 B2 B1 B0
00=absolute value change
01=value change in %.
10=limit value monitoring
11=zone monitoring
1=event-controlled ON
1=time-controlled ON
Dev:
B7 B6 B5 B4 B3 B2 B1 B0
SD saving mode
000=
1 row
001=
8 rows
010=
16 rows
011=
32 rows
100=
64 rows
101=
128 rows
Number of transmitters to be logged
( LOG/Settings/Source )
