Nokia 7705 SAR-W Series User Manual

MPLS Guide MPLS and RSVP-TE
3HE 18686 AAAB TQZZA © 2022 Nokia.
Use subject to Terms available at: www.nokia.com
235
interface
Syntax interface [ip-int-name | ip-address] [label-map [label]]
interface [ip-int-name | ip-address] statistics
Context show>router>mpls
Description This command displays MPLS interface information.
Parameters ip-int-name — identifies the network IP interface. The interface name cannot be in the
form of an IP address. Allowed values are any string up to 32 characters long
composed of printable, 7-bit ASCII characters. If the string contains special
characters (#, $, spaces, etc.), the entire string must be enclosed within double
quotes.
ip-address — specifies the system or network interface IP address
label-map label — specifies the MPLS label on which to match
Values 32 to 1023
statistics — displays IP address and the number of packets and octets sent and
received on an interface basis
Output The following output is an example of MPLS interface information, and Table 11 describes
the fields.
Output Example
ALU-12# show router mpls interface
===============================================================================
MPLS Interfaces
===============================================================================
Interface Port-id Adm Opr TE-metric
-------------------------------------------------------------------------------
system vport-1 Up Up None
Admin Groups None
Srlg Groups None
ip-10.10.1.2 1/1/1 Up Up None
Admin Groups None
Srlg Groups None
ip-10.10.4.2 1/1/2 Up Up None
Admin Groups None
Srlg Groups None
ip-10.10.3.2 1/1/3 Up Up None
Admin Groups None
Srlg Groups None
-------------------------------------------------------------------------------
Type The type of protected LSP
Table 10 Router MPLS Bypass-Tunnel Field Descriptions (Continued)
Label Description
