MPLS Guide MPLS and RSVP-TE
3HE 18686 AAAB TQZZA © 2022 Nokia.
Use subject to Terms available at: www.nokia.com
269
Next Available Lsp Index : 4
Entropy Label RSVP-TE : Enabled Entropy Label SR-TE : Enabled
===============================================================================
MPLS LSP Count
===============================================================================
Originate Transit Terminate
-------------------------------------------------------------------------------
Static LSPs 0 0 0
Dynamic LSPs 0 0 0
Detour LSPs 0 0 0
Mesh-P2P LSPs 0 N/A N/A
One Hop-P2P LSPs 0 N/A N/A
SR-TE LSPs 0 N/A N/A
===============================================================================
A:NOK-Dut-B#
Table 21 Router MPLS Status Field Descriptions
Label Description
Admin Status Down — indicates that MPLS is administratively disabled
Up — indicates that MPLS is administratively enabled
Oper Status Down — indicates that MPLS is operationally down
Up — indicates that MPLS is operationally up
FRR Object Enabled — specifies that fast reroute object is signaled for the
LSP
Disabled — specifies that fast reroute object is not signaled for
the LSP
Resignal Timer Enabled — specifies that the resignal timer is enabled for the LSP
Disabled — specifies that the resignal timer is disabled for the
LSP
Hold Timer The amount of time that the ingress node holds before
programming its data plane and declaring the LSP up to the
service module
Oper Down Reason The reason that MPLS is operationally down
Next Resignal The amount of time until the next resignal for the LSP
Dynamic Bypass Indicates whether dynamic bypass is enabled or disabled
Next Available Lsp
Index
The next free LSP index ID
