MPLS Guide MPLS and RSVP-TE
3HE 18686 AAAB TQZZA © 2022 Nokia.
Use subject to Terms available at: www.nokia.com
239
Output Example
A:ALU-48# show router mpls lsp
===============================================================================
MPLS LSPs (Originating)
===============================================================================
LSP Name To Fastfail Adm Opr
Config
-------------------------------------------------------------------------------
to-104 10.10.10.104 Yes Up Up
to-103 10.0.0.0 Yes Up Up
to-99 10.10.10.99 No Up Up
to-100 10.10.10.100 No Up Up
to-49 10.20.30.49 No Dwn Up
-------------------------------------------------------------------------------
LSPs : 5
===============================================================================
A:ALU-48#
*A:ALU-48# show router mpls lsp to-104
===============================================================================
MPLS LSPs (Originating)
===============================================================================
LSP Name To Fastfail Adm Opr
Config
-------------------------------------------------------------------------------
to-104 10.10.10.104 Yes Up Dwn
-------------------------------------------------------------------------------
LSPs : 1
===============================================================================
*A:ALU-48#
Table 12 Router MPLS LSP Field Descriptions
Label Description
LSP Name The name of the LSP used in the path
To The system IP address of the egress router for the LSP
FastFail Config enabled — fast reroute is enabled. In the event of a failure, traffic is
immediately rerouted on the precomputed protection LSP, thus
minimizing packet loss
disabled — there is no protection LSP from each node on the primary
path
Adm State Down — the path is administratively disabled
Up — the path is administratively enabled
Oper State Down — the path is operationally down
Up — the path is operationally up
LSPs The total number of LSPs configured
