MPLS and RSVP-TE
240
MPLS Guide
© 2022 Nokia.
Use subject to Terms available at: www.nokia.com
3HE 18686 AAAB TQZZA
Output Example
*A:7705:Dut-C>config>router>mpls# show router mpls lsp "to_Dut-B_1" detail
=================================================================================
MPLS LSPs (Originating) (Detail)
=================================================================================
Legend :
+ - Inherited
==================================================================================
----------------------------------------------------------------------------------
Type : Originating
----------------------------------------------------------------------------------
LSP Name : to_Dut-B_1
LSP Type : RegularLsp LSP Tunnel ID : 1
LSP Index : 1 TTM Tunnel Id : 1
From : 10.10.10.2 To : 10.10.10.3
Adm State : Up Oper State : Up
LSP Up Time : 0d 01:00:11 LSP Down Time : 0d 00:00:00
Transitions : 1 Path Changes : 1
Retry Limit : 0 Retry Timer : 20 sec
Signaling : RSVP Resv. Style : SE
Hop Limit : 255 Negotiated MTU : 1554
Adaptive : Enabled ClassType : 0
FastReroute : Disabled Oper FR : Disabled
CSPF : Disabled ADSPEC : Disabled
Metric : N/A
Load Bal Wt : 100
Include Grps : Exclude Grps :
None None
Least Fill : Disabled
Entropy Label : Enabled+ Oper Entropy Label : Enabled
Negotiated EL : Disabled
Auto BW : Disabled
LdpOverRsvp : Disabled
VprnAutoBind : Enabled
IGP Shortcut : Enabled
IGP LFA : Disabled IGP Rel Metric : Disabled
BGPTransTun : Enabled
Oper Metric : 16777215
Prop Adm Grp : Disabled
PCE Report : Inherited
PCE Compute : Disabled PCE Control : Disabled
Primary(a) : to_Dut-B_1 Up Time : 0d 01:00:12
Bandwidth : 0 Mbps
==================================================================================
Table 13 MPLS LSP Detailed Field Descriptions
Label Description
LSP Name The name of the LSP used in the path
LSP Type The type of LSP used in the path
LSP Tunnel ID The LSP tunnel identifier
