MPLS and RSVP-TE
282
MPLS Guide
© 2022 Nokia.
Use subject to Terms available at: www.nokia.com
3HE 18686 AAAB TQZZA
Output Example
*A:ALU-12>show>router>rsvp# neighbor
===============================================================================
RSVP Neighbors
===============================================================================
Legend :
LR - Local Refresh Reduction RR - Remote Refresh Reduction
LD - Local Reliable Delivery RM - Remote Node supports Message ID
===============================================================================
Neighbor Interface Hello Last Oper Flags
Change
===============================================================================
10.20.1.2 ip-10.10.1.1 N/A 0d 00:00:44
10.20.1.3 ip-10.10.2.1 N/A 0d 00:00:44
-------------------------------------------------------------------------------
Neighbors : 2
===============================================================================
session
Syntax session [session-type] [from ip-address | to ip-address | lsp-name name] [status {up |
down}] [detail]
Context show>router>rsvp
Description This command shows RSVP-TE session information.
Parameters session-type — specifies the session type
Values originate, transit, terminate, detour, detour-transit, detour-terminate,
bypass-tunnel, manual-bypass
from ip-address — specifies the IP address of the originating router
to ip-address — specifies the IP address of the egress router
name — specifies the name of the LSP used in the path
status up — specifies to display a session that is operationally up
Table 28 Router RSVP-TE Neighbor Field Descriptions
Label Description
Neighbor The IP address of the RSVP-TE neighbor
Interface The interface ID of the RSVP-TE neighbor
Hello The status of the Hello message
Last Oper Change The time of the last operational change to the connection
Flags Any flags associated with the connection to the neighbor
