MPLS Guide MPLS and RSVP-TE
3HE 18686 AAAB TQZZA © 2022 Nokia.
Use subject to Terms available at: www.nokia.com
79
3.7.6 FRR Over Unnumbered Interfaces
When the PLR is the ingress LER node and the outgoing interface of the bypass LSP
is unnumbered, the user must assign a borrowed IP address to the interface that is
different from the system interface; otherwise, the bypass LSP will not come up.
In addition, the PLR node includes the IF_ID RSVP_HOP object (C-Type = 3) in the
PATH message if the outgoing interface of the bypass LSP is unnumbered. If the
outgoing interface of the bypass LSP is numbered, the PLR node includes the IPv4
RSVP_HOP object (C-Type = 1).
When the MP node receives the PATH message over the bypass LSP, it creates the
merge-point context for the protected LSP and associates it with the existing state if
any of the following is satisfied:
• the C-Type value of the RSVP_HOP object has changed
• the C-Type is the value for the IF_ID RSVP_HOP object (C-Type = 3) and it has
not changed, but the IF_ID TLV is different
• the IPv4 Next/Previous Hop Address field in the RSVP_HOP object has
changed, regardless of the C-Type value
This behavior at the PLR and MP nodes is the same for both link protection and node
protection FRR.
See RSVP-TE Support for Unnumbered Interfaces for information on unnumbered
interfaces.
Note: If node protection FRR is enabled but the MP does not support an unnumbered
interface, the PATH message is rejected at the MP and the path is torn down.
